Single RAM Quad Coiled Tubing BOP For Oil Well 4 1/16″ X 10000psi
$0.00
More specification are available according to customer’s requirement.
Product scope
| Wellhead valves | Gate Valves, Plug Valves, Choke Valves, Check Valves, Mud Valves and various wellhead valve parts etc. |
| Wellhead Manifold | Choke and Kill Manifold, Drilling Floor Manifold, Fracturing manifold, Well Testing Manifold. |
| Wellhead Equipment | Wellhead Christmas Tree / XTree, Casing Head, Casing Hanger, Tubing Head,Tubing Hanger, Casing Spool, Tubing Spool, Drilling Spool etc. |
| Wellhead Adapter | Spacer Spool / Riser Spool ,Flange Adapter, Union Flange, Double Studded Adapter Flange, Welded Neck Flange, Blind Flange,Companion Flange, Instrument Flange,Wellhead Clamp & Hub etc. |
| Wellhead Integral Fittings | Hammer Union, Elbow, Swivel Joint, Block Cross, Block Tee, Straight Pipe, Pipe Loops etc. |
| Well Control Equipment | Annular BOP, RAM BOP, Sucker Rod BOP, BOP Stack, Wireline BOP etc |
| Surface Well Testing Package | Surface Test Tree (Flowhead), Surface Safety Valve(SSV), ESD System, Data Header, Choke Manifold, Oil Diverter manifolds, Gas Diverter Manifold |
Single RAM Quad Coiled Tubing BOP For Oil Well 4 1/16`` X 10000psi
Description
| Application: | Oil Well Pressure Control | Usage: | Oil Well Coiled Tubing Operation |
| Bore Size: | 4 1/16″ | Type: | Coiled Tubing Combi BOP |
| RAM: | Single RAM | Standard: | API 16A |
| Working Pressure: | 10000 Psi | Specification: | 4 1/16″ X 10000psi |
| Highlight: | Single RAM Coiled Tubing BOP, Oil Well Coiled Tubing BOP, 1/16″ Quad BOP Coiled Tubing | ||
Oil Well API Coiled Tubing BOP Combi BOP 4 1/16`` x 10000psi Quad BOP
Coiled Tubing BOP is an important well pressure and flow control equipment, the coiled tubing BOP is against overflow for oil, gas and water and well blowout, thus to avoid resource waste, protect equipment and human safety.
There are different types of coiled tubing BOP available including single ram, dual ram, quad ram and combi ram, in order to suit different customer needs. Each coiled tubing BOP is performed strict strength and performance tests as per API 16A.
Specification of Coiled Tubing Combi BOP
| Model | Main Bore | Tubing Size | Rated Pressure
(psi) |
Max. Hydraulic Pressure (psi) |
| 3 1/16″-10K | 3 1/16″ | 1″- 2″ | 10,000 | 3,000 |
| 4 1/16″-10K | 4 1/16″ | 1″-2 3/8″ | 10,000 | 3,000 |
| 4 1/16″-15K | 4 1/16″ | 1″-2 3/8″ | 15,000 | 3,000 |
Specification of Coiled Tubing Quad BOP
| Model | Main Bore | Tubing Size | Rated Pressure (psi) | Max. Hydraulic Pressure (psi) |
| 2 9/16″-10K | 2 9/16″ | 1″-1 1/2″ | 10,000 | 3,000 |
| 3 1/16″-10K | 3 1/16″ | 1″-2″ | 10,000 | 3,000 |
| 4 1/16″-10K | 4 1/16″ | 1″-2 5/8″ | 10,000 | 3,000 |
| 4 1/16″-15K | 4 1/16″ | 1″-2 5/8″ | 15,000 | 3,000 |
| 4 1/16″-20K | 4 1/16″ | 1″-2 7/8″ | 20,000 | 3,000 |
| 5 1/8″-10K | 5 1/8″ | 1″-2 7/8″ | 10,000 | 3,000 |
| 5 1/8″-15K | 5 1/8″ | 1″-2 7/8″ | 15,000 | 3,000 |
