API 6A Casing Head Suitable For Oil Gas Well Drilling Operation
$0.00
API 6A Casing Head Suitable For Oil Gas Well Drilling Operation
Description
| Surface Treatment: | Painting | Flange Connection: | Welded |
| Material: | Alloy Steel | Flange Material: | Alloy Steel |
| Size: | 36”X 13-3/8”X 9 5/8″ | Flange Rating: | 2000psi |
| Standard: | API 6A | Flange Type: | Weld Neck |
| Highlight: | Painting Wellhead Casing Head, API 6A Casing Head, Gas Well Drilling Casing Head | ||
Product Description:
Wellhead Casing Head is a high pressure-rated casing hanger housing designed to support and hang the casing string in a well. It is rated up to 2000psi and is available in API thread type and 13 3/8`` flange connection with welded and painted surface treatments. It is a robust and reliable casing hanger housing that provides an excellent seal to the wellhead and is ideal for high-pressure applications. The wellhead casing head is designed to provide superior performance and reliability, ensuring a safe and secure seal for the wellhead. It is made from high quality materials and is designed to withstand extreme conditions. It is an effective and efficient casing hanger housing that helps to keep the wellhead safe and secure.
Features:
- Product Name: Wellhead Casing Head
- Flange Material: Alloy Steel
- Thread Type: API
- Flange Standard: API 6A
- Flange Surface Treatment: Painting
- Flange Connection: Welded
Technical Parameters:
| 1 | EQUIPMENT – 5Kpsi SPLITTER WELLHEADS ( (2 IN 1) wellhead systems for 36”X 13-3/8”X 9 5/8 Casing scheme and 4 ½” (Single String Completion System) |
| 1.1 | LOWER HOUSING 36″ CSW 2. IN 1., 36″ SLIPLOCK BTM, C/W DBL “WQ” SEALS, W/ 20″ NOM. 2,000 PSI WP ‘D’ SHAPED STUDDED TOP PROFILE W/ TWO 20″ NOM. HANGER BOWL PREP. (20.500″ CENTERS) FOR 13-3/8″ O.D. CSG AND TWO 2″ LP SIDE OUTLETS AND TWO 2″ LP MONITOR PORTS COMPLETE WITH BULL PLUG AND 1/2″ BLEEDER PLUG |
| 1.2 | CASING HANGER 20″ X 13.3/8″ BODY, FLUTED MANDREL CASING HANGER, 20IN NOM.3000 PSI, 13-3/8IN 68 LB/FT TSH BLUE BOX THD BTM X16.500-2TPI LH STUB ACME THD TOP, W/ 13-3/8IN OD SLICKNECK AND FOUR FLOW-BY SLOTS; MIN BORE: 12.360INAPI 6A; PSL-2; M/C: DD-NL; T/C: S,T,U,VBODY MATERIAL: 4140 LAS, 80KSI YS |
| 1.3 | COMPACT SPOOL ASSEMBLY 13-5/8 NOM, TYPE ‘SSMC’ TWO STAGE, 20 NOM. OEC 2000 PSI PSI ‘D’ SHAPED FLANGE BTM. W/ 13-3/8 DOUBLE ‘T’ SEAL BTM. X 13-5/8 NOM. API 5000 PSI ‘JB’ TOP CONNECTION W/ 13-5/8 ‘SRL’ SEAL PREP TOP |
| 1.4 | TEMPORARY ABANDONMENT CAP 20 NOM ‘D-SHAPED’ FLANGE BTM W/13-3/8 DBL ‘T’ SEAL AND DBL O-RING SEAL OD. (2,000 PSI MAX WP), COMPLETED W/ 2″ LP BULL PLUG & 1/2 NPT BLEEDER PLUG. API 6A 21ST EDITION, PSL 2, T/C: U, M/C: DD-NL;BODY MAT’L: AISI 4130 75 KSI YS. |
| 1.5 | CASING HANGER 13.5/8″ X 9.5/8″ CSG HGR, 13-5/8 NOM X 9-5/8 47PPFT TENARIS BLUE BOX THD BTM X 11.500 2TPI LEFT HAND STUB ACME THD TOP W/SLICK NECK FOR SEALS; RATED WORKING PRESSURE: 6,500 PSI; API 6A 21ST ED; M/C:AA,DD-NL; T/C:U; PSL-3; PR2; GROUP 1; MIN BORE: 8.647 |
| 1.6 | TUBING HANGER 13.5/8″ X 4.1/2″ ASSEMBLY, TUBING HANGER, TYPE ‘SSMC’, 13-5/8″ NOM, W/ TWO ‘LS’ SEALS X 4-1/2″ 12.6 LB/FT TOP BOX THD BTM, 6-1/16″ EXTENDED SLICK NECK TOP W/ 6.375″-4-STUB ACME RIGHT HAND RUNNING THREAD, PREPARED WITH 4″ NOM TYPE ‘H’ BPV PROFILE, W/ FIVE 1/4″ CONTINUOUS CONTROL LINE C/W PIPE PLUGS. 3.90″ MIN. BORE; API 6A 21ST EDITION, MATERIAL CLASS: EE-1.5, FF-1.5, TEMPERATURE RATING: U, PSL-2, PR-2, BODY MAT’L: SS 410 80K YS |
