API 16A Wellhead Hub Clamp AISI 4130 PLS 3 For Connection
$0.00
| Application: | Wellhead Connection Part | Usage: | Wellhead High Pressure Part Connection |
| Material: | AISI 4130 | Production Level: | PLS 3 |
| Temperature Rating: | PU | Standard: | API 16A & API 6A |
| Product Name: | Wellhead Hub Clamp | System Working Pressure: | 10000 Psi |
| Specification: | No.5 Clamp | Ring Gasket: | BX 155 |
| Highlight: | API 16A Wellhead Hub Clamp, AISI 4130 Wellhead Hub Clamp, PLS 3 Wellhead Hub Clamp | ||
API 16A No. 5 Clamp For Wellhead Connection Clamp Hub AISI 4130
The Hub Clamps is a kind of high pressure connection component for wellhead equipment. The clamps are different from all other API equipment in regard to design and hydrotest. Clamps serve as fasteners similar to bolts, they do not come in contact with well fluid, and they may connect several API specified connectors having different nominal sizes and working pressures.
The hub clamp is designed and manufactured according to API Spec 16A, Clamps provide a reliable means to join API and other hub connections. Any of the equipment in the following list may have clamp hub connections:
Wellhead Equipment
Casing Heads
Casing Spools
Tubing Heads
Valves
Chokes
Crosses
Tees
Flowlines
Drilling Equipment
Spools
Blowout Preventers
Choke and Kill Manifolds
Technical parameter of NO. 10 Hub Clamp
| Clamp No. | Nominal Bore | Working pressure | Ring gasket | Bolt Size |
| 1 | 1 13/16 | 10000psi | BX151 | 7/8-9UNX7 |
| 2 1/16 | 5000psi | BX152 | 7/8-9UNX7 | |
| 2 | 1 13/16 | 15000psi | BX151 | 7/8-9UNX8 |
| 2 1/16 | 10000psi | BX152 | 7/8-9UNX8 | |
| 2 9/16 | 5000psi | BX151 | 7/8-9UNX8 | |
| 3 | 1 13/16 | 20000psi | BX151 | 1-8UNX9 |
| 2 1/16 | 15000psi | BX152 | 1-8UNX9 | |
| 2 1/16 | 20000psi | BX152 | 1-8UNX9 | |
| 2 9/16 | 15000psi | BX153 | 1-8UNX9 | |
| 4 | 2 9/16 | 10000psi | BX153 | 1-8UNX 8 1/2 |
| 3 1/8 | 5000psi | BX154 | 1-8UNX 8 1/2 | |
| 5 | 3 1/16 | 10000psi | BX154 | 1-8UNX 8 1/2 |
| 4 1/16 | 5000psi | BX155 | 1-8UNX 8 1/2 | |
| 6 | 2 9/16 | 20000psi | BX153 | 1 1/8-8UNX9 3/4 |
| 3 1/16 | 15000psi | BX154 | 1 1/8-8UNX9 3/4 | |
| 4 1/16 | 10000psi | BX155 | 1 1/8-8UNX9 3/4 | |
| 7 | 5 1/8 | 10000psi | BX169 | 1 3/8-8UNX12 |
| 8 | 3 1/16 | 20000psi | BX154 | 1 1/2-8UNX13 1/2 |
| 4 1/16 | 15000psi | BX155 | 1 1/2-8UNX13 1/2 | |
| 7 1/16 | 5000psi | BX156 | 1 1/2-8UNX13 1/2 | |
| 9 | 5000psi | BX157 | 1 1/2-8UNX13 1/2 | |
| 9 | 11 | 3000psi | RX53 | 1 3/8-8UNX13 |
| 10 | 4 1/16 | 20000psi | BX155 | 1 7/8-8UNX17 |
| 7 1/16 | 10000psi | BX156 | 1 7/8-8UNX17 | |
| 9 | 10000psi | BX157 | 1 7/8-8UNX17 | |
| 11 | 5000 | BX158 | 1 7/8-8UNX17 |
